Mercusys ME30 | AC1200 Wi-Fi Range Extender

Description

•







  colour

  • White

  Hardware Features

  Dimensions

  112 × 84.7 × 39 mm

  Interfaces

  1× 10/100Mbps RJ45 Port

  Button

  RESET/WPS Button

   Antenna Type

  2× External Antennas

   Power Consumption

  9.2 W



  Wireless Features

  Wireless Standards

  IEEE 802.11a/n/ac 5 GHz, IEEE 802.11b/g/n 2.4 GHz

   Frequency

  2.4 – 2.5 GHz, 5 GHz

   WiFi Speeds

  Up to 1200 Mbps (867 Mbps on 5 GHz, 300 Mbps on 2.4 GHz)
   Reception Sensitivity

  5 GHz:
  11ac HT80 MCS9 < -63 dBm
  2.4 GHz:
  11n HT40 MCS7 < -70 dBm

   Transmission Power

  < 20 dBm

   Wireless Security

  WPA-PSK/WPA2-PSK



  Others

  Certifications

  CE, RoHS

   Package Contents

  • Wi-Fi Range Extender (ME30)
  • Quick Installation Guide

   Environment

  • Operating Temperature: 0°C~40°C (32°F~104°F)
  • Operating Humidity: 10%~90% Non-Condensing



  *The preceding specifications are theoretical values based on product design. To provide accurate product information, specifications, and features, the manufacture company may make real-time adjustments to the preceding specifications, so that they match the product performance, specifications, indexes, and components of the actual product. Product information is subject to such changes and adjustments without notice.
