Mercusys MB115-4G | 300 Mbps Wireless N 4G LTE Router

Description

• 4G network – Share internet access with up to 32 Wi-Fi devices and enjoy download speeds of up to 150 Mbps
• Plug a SIM card and play – No configurations needed, compatibility of SIM cards are assured by years of field tests*
• 300 Mbps WiFi – Fast WiFi speeds up to 300 Mbps to share your network.
• Maximum Network Coverage – Enjoy stable and efficient connections to every device thanks to the four external antennas
• Wi-Fi router mode – Plug an Ethernet cable into the LAN/WAN port for flexible access if you can’t get a 4G connection


  colour

  • Black

  Hardware Features

  Dimensions

   219 × 140 × 32 mm

  (8.62 × 5.51 × 1.26 in)

  Interfaces

  1× 10/100Mbps LAN/WAN Port

  3× 10/100Mbps LAN Ports

  1× Nano SIM Card Slot

  Antenna

  2× External 4G LTE Antennas,
  2× External Wi-Fi Antennas

  Button

  WPS、Reset Button

  External Power Supply

  9V/0.85A

  LED

  1× Power
  1× Internet
  1× LAN
  3× Signal

  LTE Standard

  Cat 4
  150/50Mbps DL/UL

  Wireless Features

  Network Type

  EU:
  FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700 MHz)
  TDD-LTE: B38/B40 (2600/2300 MHz)
  HSPA+/UMTS: B1/B5/B8 (2100/850/900 MHz)
  CN:
  FDD-LTE: B1/B3/B5/B8 (2100/1800/850/900 MHz)
  TDD-LTE: B38/B40 (2600/2300 MHz)
  HSPA+/UMTS: B1/B5/B8 (2100/850/900 MHz)

  UN:

  FDD-LTE: B1/B2/B3/B4/B5/B7/B8/B28/B66 (2100/1900/1800/1700/850/2600/900/700/1700 ΜHz)

  TDD-LTE: B40 (2300 MHz)

  HSPA+/UMTS: B1/B2/B4/B5/B8 (2100/1900/1700/850/900 MHz)

  Wi-Fi Class

  N300

  Wi-Fi (2.4 GHz)

  300 Mbps

  Wireless Standards

  IEEE 802.11b/g/n

  Frequency

  2.4 GHz

  Reception Sensitivity

  11g 54M: -74.5 dBm
  11n HT20 MCS7: -73.5 dBm
  11n HT40 MCS7: -70.5 dBm

  Transmission Power

  < 20 dBm (2.4 GHz)

  Wireless Security

  WPA-PSK / WPA2-PSK

  Wireless Functions

  smart connect
  WPS
  Wireless Schedule
  Wireless Clients Statistics

  Software Features

  Operation Mode

  3G/4G Router
  Wireless Router

  Cellular Mode

  4G Preferred
  4G Only
  3G Only

  Cellular APN

  Data Roaming
  Network Search
  Profile Create
  APN Settings
  ISP File Upgrade
  PIN Management

  WAN Mode

  Dynamic IP
  Static IP
  PPPoE
  PPTP
  L2TP

  NAT Forwarding

  ALG
  Virtual Server
  Port Triggering
  UPnP
  DMZ

  Protocols

  IPv4, IPv6

  Data Settings

  Data Statistics
  Data Limit

  Parental Controls

  Time Control
  Website Filtering

  Guest Network

  2.4 GHz Guest Network

  DHCP

  Server
  DHCP Client List
  Address Reservation

  DDNS

  MERCUSYS DDNS
  DynDns
  NO-IP

  SMS

  Inbox
  New Message
  Outbox
  Drafts

  Security

  IPv4 SPI Firewall
  Access Control
  Service Filtering
  IP & MAC Binding
  IPv6 Firewall

  System Settings

  Time Settings
  LED Control
  Diagnostics
  Firmware Upgrade
  Backup&Restore
  Reboot
  Administration
  System Log
  CWMP Settings

  Device Management

  MERCUSYS APP
  Web GUI

  System Language

  English
  Spanish
  Italian
  Polish
  Russian

  TR-069
